Size: 43cm
Color(s): Black/Gray
Main frame: Fuji Elios 2 custom butted Cro-Moly with outer butted seat tube, Double water bottle mounts
Rear triangle: Fuji Elios 2 custom tapered Cro-Moly with track dropout, bridge drilled for rear brake
Fork: Fuji 1 1/8” Custom Triple Butted Cro-Moly, crown drilled for front brake
Crankset: RPM CFM-100 Forged Alloy, 48T
Bottom bracket: Sealed cartridge bearing ST
Pedals: Wellgo Road w/clips and straps
Front derailleur: Nil
Rear derailleur: Nil
Shifters: Nil
Cassette: 15T Fixed w/lockring
Chain: KMC Z-410
Front hub: Formula Alloy Track, 32H
Rear hub: Formula Alloy Track, 32H Flip Flop
Spokes: 14G Stainless Steel
Rims: Alex RPD-15 Double Wall Road Rims, 32H
Tires: Kenda K-152 Road Tire, 650 x 23c
Tubes: Kenda Presta
Brake set: Nil
Brake levers: Nil
Headset: Ritchey LB 1 1/8” Threadless
Handlebar: Fuji 6061 Butted Road, 26mm Anatomical Drops
Stem: Fuji Pro AL forged , +/-7 degree
Tape/grip: Fuji custom cork wrap
Saddle: Fuji Superlight Racing
Seat post: Fuji Micro Adjust alloy, 250mm
Seat clamp: Fuji Ultralite alloy, 28.6mm, Laser Etched
Other: Nil
Weight, lb./kg.:
**Specifications are subject to change without notice.**
Geometry
|
|
Description
|
Size 1
|
|
A
|
SEAT TUBE, CENTER TO TOP
|
430.0
|
|
C-2
|
EFFECTIVE TOP TUBE LENGTH
|
500.0
|
|
D
|
CHAIN STAY
|
395.0
|
|
E
|
BB DROP
|
33.0
|
|
F
|
FORK OFFSET
|
40.0
|
|
G
|
HEAD TUBE ANGLE
|
72.0
|
|
H
|
SEAT TUBE ANGLE
|
76.0
|
|
I
|
WHEEL BASE
|
958.9
|
|
J
|
STAND OVER HEIGHT
|
697.3
|
|
|
HEAD TUBE LENGTH
|
90.0
|
|
|
STEM LENGTH
|
70.0
|
|
|
STEM ANGLE
|
0
|
|
|
HANDLEBAR WIDTH
|
390.0
|
|
|
HANDLEBAR RISE
|
NA
|
|
|
CRANK LENGTH
|
165.0
|
|
|
TOE CLIP SIZE
|
NA
|
|
|
SEAT POST DIAMETER
|
27.2
|
**Geometry is subject to change without notice.**
Bikes are Brand New, Boxed, and in stock.
P&P Details.
UK Mainland – DHL for bikes/larger accessories, Royal Mail “Signed For” for smaller accessories
Highlands and Islands – Royal Mail Standard Parcels for bikes, Royal Mail “Signed For” for accessories
Ireland and Rest of Europe – Royal Mail International Signed For
Collection – our retail outlet is in Hindley Green near Wigan, please call 01942 254131 to confirm opening times and for address.
Please be sure to select the correct delivery option from the dropdown menu when going through checkout/paypal.
P&P Pricing
We don’t offer “Free Delivery” as its never free, it becomes an overhead so inflates the price of the product, and penalises those people that choose to collect, instead we price our product lower and charge our carriage fairly and we do not make money from it, the dearer the product the higher the carriage to cover the higher insurance. If you have your own cheaper carrier please feel free to select collection and notify us of who is coming and when. Please also note that Paypal insist we use a signed for trackable service which limits the carriers we can use. Parcel2Go are one of our carriers, click the link if you wish to view their pricing (don’t forget the appropriate insurance).
Technical
Our customer technical helpline is available should you require assistance assembling the bike. Cycle is supplied with an owners manual which contains maintenance and service details. Assembly typically involves inserting the handlebar assembly, seat and post and front wheel, and tightening the fixings for these parts, a general safety check and operation check on gears, brakes etc is needed before first riding. Please have assembled by a local bike shop if you are unsure you can do it properly.
Warranty
2 year frame/fork, 12 month parts, manufacturers warranty (please note - this does not cover wear and tear items such as tyres, tubes, brake blocks, etc, misuse related damage, or damage caused by incorrect assembly prior to riding).
