CCTV 8 CH PC PCI 240FPS Real Time DVR Card w/ Software

If you want to buy more other items ,you can click " Here"

8 CH real time and 32 CH non-real time DVR Card TV-OUT,

8Ch Audio /Motion Detect /PTZ Control /Display Mask

Support Vista / Watchdog Function

Parameter

• Total Capacity: PAL 200 FPS ( Playback 200 FPS) / NTSC: 240 FPS ( Playback 240 FPS)
• Compression Format: H.264
• Chipset: TECHWELL 6805 chip,10Bit High Quality Image
• Video Input: 8 CH real time
• Audio Input: 8 CH
• TV output: 1 Channel TV output
• Image Resolution Displaying Resolution: PAL: 352X288 NTSC: 320X240
• Recording Resolution: PAL: 352X288 NTSC: 320X240
• Data Storage: 100-150M/Hour/channel
• Color Adjust: Adjustable Light,Contrast,Hue,Saturation by Individual Camera
• Resolution: 160X120 / 240X180 / 320X240 / 352X288 / 480X360 / 640X480
• Record Mode: Continuous / Schedule Recording / Alarm Triggering
• Compression: Enhanced MPEG4 / H.264 Format, Frame Size: .1K~2.5K
• Multi-task: Monitoring/Recording/PTZ Control/Remote/Backup
• Motion Detect 16 Zone X Multi Area for each camera
• Storage: HDD/VDRAM/CD-RW/DAT/MO/ZIP/RAID. Up to 24 drives
• PTZ: RS422/RS485 Controlled PTZ & Light/Power/Wiper
• Playback Speed: Forward/Back/Step/Fast 1X,2X,4x,8X/Slow 1X,1/2 X,1/4 X,1/8X
• User Right: Multi User with Personal User name/Password/User rights,Remote Users
• O.S.: Windows 2000/XP/NT/Vista
• Water Mark: Water Mark,Not Editable & Not Replaceable
• Network: PSTN/ISDN/LAN/ADSL/Internet
• Remote: LAN & ADSL: Real Time In 320X240,PSTN: 5-25fps In QCIF
• IE Remote View: Remote Browse by MS Internet Explorer
• Remote Control: Full Function Remote Control & Remote Audio Transmission
• Remote Rec.: Remote Playback,Remote Recording,& Emergency Recording
• Speed dome: Pelco-D/Pelco-P Protocols & Sequence
• E-map: Provide electronic map that lays out the location of video camera (At Server)/ lays out the location of Server (At Client)
• Display Mask: Support Camera mask (Just not show on Screen),Password to Playback Recording Files
• Duplex Voice: Server & Client can talk by microphone
• Alarm I/O port: Support 6 CH Alarm signal input & 4 CH Relay output with SV Alarm I/O Card
• Support 23 languages:

English,Portuguese,Turkish,Polish,Hebrew,Spanish,German,Czech,Russia,French,Italian,Persian,Arabic,

Thai,Japanese,Korean,Romanian,Dutch,Danish,Indian, Croatian,Old Chinese and Simplified Chinese.

• Watchdog: Yes

Specification

• PCI2.2 criterion Comply with PCI2.2 Criterion,support PNP
• Video Input connector BNC input cable
• Video Input Impedance 75Ω
• Consumption 6W(Compact structure and stability system)
• Card Dimension 192 (L) X120 (W) X19 (H) mm
• Net Weight 630g
• Temperature -10℃～+50℃

Configuration

Operation System :Windows 2000/XP/NT
Recommendations :P4/2.4G，DDR256M，ATI 64M or Above (VIA chipset motherboard is not compatible with SKY-6808i)

Descriptions:

Supports the building of digital video surveillance recording system in your personal computer. It also enables multi screen monitoring, split screen mode and rotating display support. This is specially suitable for shops, ware house, homes for nanny cam etc.

Package include:

• 1 x SkyBest DVR Card SKY-6808i
• 2 x Video Audio Cable
• 1 x CD
